Typhoon TY15
Fluimac Typhoon TY15 is a vertical plastic centrifugal pump for fixed installation, submerged directly in the tank. It is designed for fast tank emptying and for recirculation of aggressive and contaminated liquids with a viscosity of up to 200 cps, including liquids with small suspended solids. The electric motor drives the shaft and the semi-open impeller through a Fluimac flexible coupling, which absorbs peak loads and torsional vibrations. The pump reaches a flow rate of up to 15 m³/h and a head of up to 12 m and is available in lengths of 250, 500, 800 and 1000 mm. It is supplied with a 50 Hz 2-pole electric motor (2900 rpm). A version with a 4-pole motor (1400 rpm) is also available on request. The casing is made of PP or PVDF. See all pumps in the series Typhoon. Learn more about centrifugal pump technology here.
- Suction connection (inlet): 1 1/2″ BSPP (female thread)
- Delivery connection (outlet): 1″ BSPP (male thread)
- Maximum flow rate: 15 m³/h
- Maximum head: 12 m
- Available lengths: 250, 500, 800, 1000 mm
- Maximum viscosity: 200 cps
- Impeller: semi-open
- Motor power: 0.75 / 1.1 / 1.5 kW
- Motor: 50 Hz, 2-pole (2900 rpm)
- Materials: PP, PVDF
- Temperature: PP -5 °C +65 °C, PVDF -20 °C +95 °C
Available materials
PP
-5 °C +65 °C
PVDF
-20 °C +95 °C
Lengths and technical documentation
Typhoon TY15 is available in lengths of 250, 500, 800 and 1000 mm – choose the length according to the depth of the tank. We provide the dimensional drawing, motor tables and order code on request.
