- Fluid connections: Tri-Clamp 3''
- Air connections: 3/4'' BSP
- Max flow-rate: 1050 l/min
- Max air pressure: 8 bar
- Max Viscosity: 55.000 cps
| Model | Casing | Diaphragm | Balls | Seats | Gasket | Connections | Atex | Ports |
|---|---|---|---|---|---|---|---|---|
| PF1000 | S=SS POLISHED | HT = HYTREL+PTFE | T = PTFE S = SS | S = SS | T =PTFE | 1 = BSP 3 = TRI-CLAMP | - = zone 2 x = zone 1 | AB = STANDART |
